Create an exceptionally wide, aggressive stance with the RealWheel 10x16 Aluminum Golf Cart Wheel. Measuring 10 inches in diameter and 16 inches wide, this specialty aluminum golf cart wheel is designed for highly customized, lifted, long-travel, and off-road golf cart builds.
RealWheel constructs this extra-wide golf cart wheel from structural-quality 6061-T6 aircraft-grade aluminum. Certified double heat treatment, spun wheel halves, precision CNC machining, and welded construction combine to deliver a strong, straight, and consistently shaped wheel for demanding custom applications.
⚠️ IMPORTANT: PRICE IS FOR ONE (1) WHEEL
Each order quantity includes ONE (1) RealWheel aluminum wheel only. Tires, lug nuts, valve stems, and additional wheels are not included. Select a quantity of 4 to order four wheels.
MADE-TO-ORDER LEAD TIME: APPROXIMATELY 4–8 WEEKS
This specialty wheel is manufactured to order. Production times are estimates and may vary. Please allow approximately 4–8 weeks for manufacturing before shipment.
Please note the size orientation: This wheel measures 10 inches in diameter by 16 inches wide. It is an exceptionally wide 10-inch wheel and should not be confused with a 16-inch-diameter automotive-style golf cart wheel.
RealWheel 10x16 Specifications
| Wheel Diameter |
10 inches |
| Wheel Width |
16 inches |
| Bolt Pattern |
4x4 inches (4x101.6 mm) |
| Backspacing |
8 inches |
| Material |
6061-T6 aircraft-grade aluminum |
| Tire Configuration |
Tubeless |
| Construction |
Spun, CNC-machined, heat-treated, and welded aluminum |
Aircraft-Grade Aluminum Construction
- Structural-quality 6061-T6 aircraft-grade aluminum
- Certified double heat treatment for enhanced material strength
- CNC machining maintains precise manufacturing tolerances
- Spun wheel halves promote uniform material thickness
- Spun construction avoids the inconsistencies associated with stamped wheel halves
- Welded construction creates a strong, permanent wheel assembly
- Engineered to provide a round, straight, and consistent wheel profile
- Tubeless design for use with a compatible tubeless tire and valve stem
RealWheel Safe-Loc Safety Bead
The exclusive Safe-Loc safety bead helps retain a properly installed tire bead during demanding recreational use. This specialized design can eliminate the need for a separate beadlock in many applications while maintaining a clean and lightweight wheel assembly.
A separate beadlock may still be appropriate for extreme conditions or unusually low tire pressures. Always follow the tire manufacturer’s approved rim-width and inflation specifications.
Golf Cart Fitment
The standard 4x4-inch bolt pattern is used by many Club Car, EZGO, Yamaha, and other golf carts. However, the RealWheel 10x16 is an exceptionally wide specialty wheel and is not intended as a direct replacement for an original factory golf cart wheel.
The 8-inch backspacing positions a substantial portion of the wheel toward the inside of the cart. Suspension, frame, steering, brake, motor, transaxle, and body clearances must be measured carefully before ordering.
Confirm all of the following before purchasing:
- Your golf cart uses a 4x4-inch four-lug bolt pattern
- The 8-inch backspacing clears all suspension and drivetrain components
- Your selected tire is approved for a 10-inch-diameter by 16-inch-wide wheel
- Your lift kit, long-travel suspension, or wheel-spacing configuration provides sufficient clearance
- The assembled wheel and tire will clear the body and frame throughout the complete steering range
- The wheel and tire will not contact the cart through full suspension compression and extension
Fitment warning: Significant vehicle modifications may be required. Carefully measure your cart and consult a qualified golf cart builder before ordering this made-to-order wheel.
Recommended Tire Application
Kenda Bear Claw tires are a popular option for extra-wide RealWheel applications. Tire availability and approved wheel-width ranges vary by tire size, so verify compatibility directly with the tire manufacturer or a qualified tire installer.
Do not install a tire unless the RealWheel’s 16-inch width falls within the tire manufacturer’s approved rim-width range.
Why Choose a RealWheel 10x16?
- Creates a dramatic, extra-wide custom golf cart stance
- Supports specialized flotation and mud-tire applications
- Ideal for compatible lifted, long-travel, and off-road builds
- Aircraft-grade aluminum provides strength without the weight of a comparable steel design
- Precision manufacturing promotes consistent wheel shape and rotation
- Tubeless construction simplifies compatible tire installation
- Safe-Loc bead design provides additional tire-bead security
- Purpose-built construction offers an alternative to conventional cast golf cart wheels
What Is Included?
- One (1) RealWheel 10-inch-diameter by 16-inch-wide aluminum wheel
Not Included
- Tire
- Valve stem
- Lug nuts
- Center cap
- Wheel spacers or adapters
- Lift kit or long-travel suspension
- Additional wheels
Installation Notes
- Professional tire mounting and wheel installation are strongly recommended.
- Use a compatible tubeless valve stem and a tire approved for a 10x16 wheel.
- Verify the correct lug-nut thread, seat style, and torque for your golf cart.
- Check wheel, tire, steering, suspension, body, and drivetrain clearance before operating the cart.
- Recheck lug-nut torque after the initial break-in period.
Ordering reminder: The listed price is for one wheel. Select a quantity of 4 if your build requires four matching wheels.
Extra-wide wheels and tires can substantially change steering effort, suspension loading, braking, handling, and vehicle stability. Install only on a properly engineered golf cart and operate responsibly.
